Lenovo Legion Y34wz-30 34-inch VA Curved WQHD 180Hz USB-C Docking Gaming Monitor

Brand

Legion

Screen Size

34 inch

Panel Type

VA

Resolution

3440 x 1440

Refresh Rate

165Hz (180Hz Overclock)

Response Time

1ms (MPRT), 2ms (Level 4), 4ms (Level 3), 6ms (Level 2), 8ms
(Level 1), 11ms (G to G)

Contrast Ratio

3000:1

Color Coverage

95% DCI-P3, 99% sRGB, 104% DCI-P3, 131% sRGB (Color area
ratio)

Color Depth

10-bit

Color Support

1.07 Billion

Color Calibration Accuracy

Avg Delta E < 2

Gaming

Yes

Backlight

Mini LED

Connection Type

1 x USB Type-C (DP1.4 32.4 Gbps for 4 lanes Alt mode), 2 x
HDMI 2.1, 1 x DP 1.4, 1 x Ethernet, 2 x USB3.2 Gen2 (1 by USB Type-C, 1 by
USB3.2 Gen1 Type-B), 4 x USB3.2 Gen1 Type-A + 1 x USB3.2 Gen1 Type-C (15W), 1 x
Audio Out (3.5mm)

USB Type-C

Yes

AMD FreeSync

AMD FreeSync™ Premium Pro Technology

Integrated Speaker

Yes (2 x 5W)

Brightness

720 cd/㎡ (typical), 1200 cd/㎡ (peak)

Aspect Ratio

21:9

Maximum Resolution

3440 x 1440

Mechanical

Stand

Tilt Angle (-5° / 22°), Swivel Angle (+30° / -30°), Lift
Range (135 mm)

Viewing Angle

178° / 178°

Height-Adjustable

Yes

Near Edgeless

3-side NearEdgeless

Dimension

Head only Dimensions

124.6 x 367.8 x 807.2mm, 4.91 x 14.48 x 31.78 inches

Weight Head Only

8.2kg /18.06 lbs

Weight with Package

16.6 kg / 36.60 lbs.

Weight without Package

10.5kg / 23.08 lbs

Dimensions without Package

320.1 x 541.3 x 807.2mm, 12.60 x 21.31 x 31.78 inches

Power

Power Requirement

100 - 240 VAC, 50 - 60 Hz

Power Consumption

55W Typ, 330W Max, 0.5W Sleep, 0.3W Power Off

Others

Other Special Features

True Split, PiP/PbP, KVM, Smart RGB Lighting, Ambient Light
Sensor, Smart Power, ClearMR7000

Included Accessory

DP cable, USB-C to USB-C Power Delivery 140W, USB Type-B to
Type-A Cable

Eye Caring

Yes

Software/Driver

Yes (Lenovo Artery, Lenovo Display Control Center)

Warranty

3 years limited

Kensington Lock

Yes

Superior Display Performance

Y34wz-30 comes equipped with 1.07 billon color support and 10-bit color depth, and thanks to 104% DCI-P3 and 131% sRGB color area with Delta E<2, the monitor can deliver accurate and vivid color.

34”21:9 Ultra-wide Curved Monitor

Get immersed in stunning gaming visuals with the 34-inch WQHD resolution, 21:9 Ultra-wide,1500R curved display.

Immerse Yourself in a Gorgeous Virtual World

Y34wz-30 with mini-LED technology can provide excellent HDR performance certified by VESA DisplayHDR™ 1000, which enriches the details of light and shade and makes the game picture look more realistic

Boost Experience for Everyday Using Universal Connectivity

Y34wz-30’s USB Type-C (DP1.4 32.4 Gbps for 4 lanes Alt mode) port acts as one docking solution so users can only connect one USB-C port to deliver the video signal, power, and data to notebook and mobile devices. The USB-C port also provides up to 140W of power via Lenovo unique Smart Power technology, which can dynamically charge the devices and save power.

AI Empower Your Lifestyle Smart Network Optimization

• The 2.5G RJ45 with Smart Network Optimization technology can provide a wired Ethernet connection for the devices that have no port. For those devices already equipped with an RJ45 port, the 2.5G RJ45 on the monitor can build a dual connection to optimize the network environment.

• By working with Realtek Dragon software, the monitor can detect applications on the PC and optimize the network connection automatically, easily managing network bandwidth.

Smart Ambient Brightness Sensor

Y34wz-30 comes equipped with a smart ambient brightness sensor, which can detect ambient light and adjust the monitor brightness automatically.

Audio-Visual Experience

With 2 x 5W speakers, you can enjoy immersive stereo audio when you play games, watch videos, and listen to music

Live Stream Support

Y34wz-30 supports easy deployment of the LC50 modular camera. You can effortlessly create your own live studio.

Lenovo Artery Software

Lenovo Artery (Lenovo Display Control Center) software can help you quickly and easily adjust your Lenovo monitor without complicated OSD operations. It not only adjusts monitor display settings, but also manages charging power, switching ports, and more custom options. Lenovo Artery also provides special gaming tools to help you win the game.

RGB Lighting for Gaming Atmosphere

Y34wz-30 has RGB lighting on the bottom of the front bezel to strengthen the gaming atmosphere. You can customize lighting effects through the Artery software (Lenovo Display Control Center). Lighting can also be changed automatically according to screen content, sound volume, and keyboard & mouse movement speed.

Ergonomic & Unique Design

A stylish and sturdy monitor stand with lift, tilt, pivot, and swivel functionality makes it easy to use. The ergonomic will satisfy customer requirement for height adjustment and different angle use.

• Kensington Lock
• Power
• HDMI 2.1
• DisplayPort 1.4
• USB-C
• USB-B
• USB-C
• Ethernet
• USB 3.2 Gen 1 Type-A
