Printing Technology
Fused Deposition Modeling
Build Volume (W x D x H)
256 x 256 x 256 mm³
Body
- Chassis: Plastic and Steel
- Outer Frame: Plastic and Glass
Physical Dimensions
392 x 406 x 478 mm³
Net Weight
14.9 kg
Toolhead
- Extruder Gear: Hardened Steel
- Nozzle: Hardened Steel
- Max Nozzle Temperature: 300 °C
- Included Nozzle Diameter: 0.4 mm
- Supported Nozzle Diameter: 0.2 mm, 0.4 mm, 0.6 mm, 0.8 mm
- Filament Cutter: Built-in
- Filament Diameter: 1.75 mm
- Extruder Motor: Bambu Lab High-precision Permanent Magnet Synchronous Motor
Heatbed
- Build Plate Material: Flexible Steel Plate
- Included Build Plate Type: Textured PEI Plate
- Supported Build Plate Type: Textured PEI plate, Smooth PEI Plate, Cool Plate SuperTack
- Max Heatbed Temperature: 110 °C
Speed
- Max Speed of Toolhead: 600 mm/s
- Max Acceleration of Toolhead: 20,000 mm/s²
- Max Flow for Hotend (Standard Flow Hotend): 40 mm³/s (Test parameters: 250 mm round model with a single outer wall; Bambu Lab ABS; 280 °C printing temperature)
Air Purification
- Activated Carbon Filter Type: Granulated Coconut Shell
- VOC Filtration: Supported
- Particulate Matter Filtration: Supported
Cooling
- Part Cooling Fan: Closed Loop Control
- Cooling Fan for Hotend: Closed Loop Control
- Auxiliary Part Cooling Fan: Closed Loop Control
Filament Supported
PLA, PETG, ABS, ASA, TPU, Support for PLA, Support for PLA/PETG, Support for ABS, PET, PA, PC, PVA, PLA-CF, PETG CF, ABS GF, ASA-CF, PA6-CF, PA6-GF, PAHT CF, PPA-CF, PET CF
Sensor
- Camera: Built-in; 1920 x 1080; 30 fps HD
- Door Sensor: Supported
- Filament Run Out Sensor: Supported
- Filament Tangle Sensor: Supported
- Filament Odometry: Supported with AMS
- Power Loss Recovery: Supported
Electrical Requirements
- Voltage: 100-120 VAC / 200-240 VAC, 50/60 Hz
- Max Power*: 1200 W@220 V / 1000 W@110 V
- PLA Steady-State Power: 200 W@220 V / 200 W@110 V (PLA printing)
Electronics
- Touchscreen: 5-inch 854 x 480 Touchscreen
- Storage: Built-in 8 GB EMMC and USB Port
- Control Interface: Touchscreen, mobile App, PC App
- Motion Controller: Dual-core Cortex-M4 and Single-core Cortex-M7
- Application Processor: Quad-core 1.5 GHz ARM A7
- Neural Processing Unit: 2 TOPS
Software
- Slicer: Bambu Studio
- Supports third-party slicers which export standard G-code, such as Super Slicer, PrusaSlicer and Cura, but certain advanced features may not be supported.
- Supported Operating System: MacOS, Windows, Linux
Network Control
- Ethernet: Not Available
- Wireless Network: Dual-Band Wi-Fi
- Network Kill Switch: Not Available
- Removable Network Module: Not Available
- 802.1X Network Access Control: Not Available
Wi-Fi
- Operating Frequency: 2412 - 2472 MHz, 5150 - 5850 MHz (FCC/CE); 2400 - 2483.5 MHz, 5150 - 5850 MHz (SRRC)
- Wi-Fi Transmitter Power (EIRP): 2.4 GHz: <23 dBm (FCC); <20 dBm (CE/SRRC/MIC)
- 5 GHz Band1/2: <23 dBm (FCC/CE/SRRC/MIC)
- 5 GHz Band3: <30 dBm (CE); <24 dBm (FCC)
- 5 GHz Band4: <23 dBm (FCC/SRRC); <14 dBm (CE)
- Wi-Fi Protocol: IEEE 802.11 a/b/g/n
* To ensure the heatbed quickly reaches the needed temperature (35-110 °C), the printer will maintain maximum power for about 3-5 minutes.
