Printing Technology
Fused Deposition Modeling
Build Volume (W x D x H)
- Single Nozzle Printing: 325 x 320 x 325 mm³
- Dual Nozzle Printing: 300 x 320 x 325 mm³
- Total Volume for Two Nozzles: 350 x 320 x 325 mm³
Chassis & Shell
Aluminum, Steel, Plastic and Glass
Laser Safety Windows
Equipped on Laser Edition, normal H2D can upgrade through Laser Upgrade Kit
Air Assist Pump
Equipped on Laser Edition, normal H2D can upgrade through Laser Upgrade Kit
Physical Dimensions
492 x 514 x 626 mm³
Net Weight
31 kg
Toolhead
- Hotend: All Metal
- Extruder Gear: Hardened Steel
- Nozzle: Hardened Steel
- Max Nozzle Temperature: 350 °C
- Included Nozzle Diameter: 0.4 mm
- Supported Nozzle Diameter: 0.2 mm, 0.4 mm, 0.6 mm, 0.8 mm
- Filament Diameter: 1.75 mm
- Extruder Motor: Bambu Lab High precision Permanent Magnet Synchronous Motor
Heatbed
- Supported Build Plate Type: Textured PEI plate, Smooth PEI Plate
- Max Heatbed Temperature: 120 °C*
Speed
- Max Speed of Toolhead: 1000 mm/s
- Max Acceleration of Toolhead: 20,000 mm/s²
- Max Flow for Hotend (Standard Flow Hotend): 40 mm³/s (Test parameters: 250 mm round model with a single outer wall; Bambu Lab ABS; 280 °C printing temperature)
- Max Flow for Hotend (Optional High Flow Hotend): 65 mm³/s (Test parameters: 250 mm round model with a single outer wall; Bambu Lab ABS; 280 °C printing temperature)
Chamber Temperature Control
- Active Chamber Heating: Supported
- Max Temperature: 65 °C
Air Purification
- Pre-filter Grade: G3
- HEPA Filter Grade: H12
- Activated Carbon Filter Type: Granulated Coconut Shell
Cooling
- Part Cooling Fan: Closed Loop Control
- Auxiliary Part Cooling Fan: Closed Loop Control
- Chamber Heat Circulation Fan: Closed Loop Control
- Cooling Fan for Hotend: Closed Loop Control
- Main Control Board Fan: Closed Loop Control
- Chamber Exhaust Fan: Closed Loop Control
Supported Filament Type
PLA, PETG, TPU, PVA, BVOH, ABS, ASA, PC, PA, PET, Carbon/Glass Fiber Reinforced PLA, PETG, PA, PET, PC, ABS, ASA, PPA CF/GF, PPS, PPS CF/GF
Sensor
- Live View Camera: Built-in; 1920 x 1080
- Nozzle Camera: Built-in; 1920 x 1080
- BirdsEye Camera: Built-in; 3264 x 2448 (Equipped with Laser Edition)
- Toolhead Camera: Built-in; 1920 x 1080
- Door Sensor: Supported
- Filament Run Out Sensor: Supported
- Filament Tangle Sensor: Supported
- Filament Odometry: Supported with AMS
- Power Loss Recovery: Supported
Electrical Requirements
- Voltage: 100-120 VAC / 200-240 VAC, 50/60 Hz
- Max Power*: 2200 W@220 V / 1320 W@110 V
- Average Power: 1050 W@220 V / 1050 W@110 V
Electronics
- Touchscreen: 5-inch 720 x 1280 Touchscreen
- Storage: Built-in 8 GB EMMC and USB Port
- Control Interface: Touchscreen, mobile App, PC App
- Neural Processing Unit: 2 TOPS
Software
- Slicer & Software: Bambu Studio, Bambu Suite, Bambu Handy
- Supports third-party slicers which export standard G-code, such as Super Slicer, PrusaSlicer and Cura, but certain advanced features may not be supported.
- Supported Operating System: MacOS, Windows
Wi-Fi
- Operating Frequency: 2412-2472 MHz, 5150-5850 MHz (FCC/CE); 2400-2483.5 MHz, 5150-5850 MHz (SRRC)
- Wi-Fi Transmitter Power (EIRP): 2.4 GHz: <23 dBm (FCC); <20 dBm (CE/SRRC/MIC)
- 5 GHz Band1/2: <23 dBm (FCC/CE/SRRC/MIC)
- 5 GHz Band3: <30 dBm (CE); <24 dBm (FCC)
- 5 GHz Band4: <23 dBm (FCC/SRRC); <14 dBm (CE)
- Wi-Fi Protocol: IEEE 802.11 a/b/g/n
10W & 40W Laser Module
- Laser Type: Semiconductor Laser
- Laser Wavelength: Engraving Laser: 455 nm ± 5 nm Blue Light; Height Measuring Laser: 850 nm ± 5 nm Infrared Light
- Laser Power: 10 W ± 1 W; 40 W ± 2 W
- Laser Spot Dimension: 10W: 0.03 mm x 0.14 mm; 40W: 0.14 mm x 0.2 mm
- Working Temperature: 0 °C - 35 °C
- Max Engraving Speed: 10W: 400 mm/s; 40W: 1000 mm/s
- Max Cutting Thickness: 10W: 5 mm; 40W: 15 mm (Basswood Plywood)
- Laser Safety Class for Laser Module: Class 4
- Overall Laser Safety Class*: Class 1
- Engraving Area: 10W: 310 mm x 270 mm; 40W: 310 mm x 250 mm
- XY Positioning Accuracy: < 0.3 mm
- Z Height Measuring Method: Micro Lidar
- Z Height Measuring Accuracy: ± 0.1 mm
- Flame Detection: Supported
- Temperature Detection: Supported
- Door Sensor: Supported
- Laser Module Installation Detection: Supported
- Safety Key: Included
- Ventilation Pipe Adapter Outer Diameter: 100 mm
- Supported Material Type: Wood, rubber, metal sheet, leather, dark acrylic, stone, and more
Cutting Module
- Cutting Area: 300 x 285 mm²
- Drawing Area: 300 x 255 mm²
- Supported Pen Diameter: 10.5 mm - 12.5 mm
- Cutting Mat Type: LightGrip and StrongGrip Cutting Mats
- Blade Type: 45° x 0.35 mm
- Blade Pressure Range: 50 gf - 600 gf
- Max Cutting Thickness: 0.5 mm
- Blade and Pen Recognition: Supported
- Cutting Mat Type Detection: Supported
- Supported Image Type: Bitmap and Vector Images
- Supported Material Type: Paper, vinyl, leather, and more
*To ensure the heatbed quickly reaches the needed temperature, the printer will maintain maximum power for no more than 3 minutes.
